Specs:

• The bucket is fully made of high-strength steel plates, which improves wear resistance and impact resistance by more than 30% and has a longer service life.
• The lubricating oil passages at key hinge points are optimized, and holes are no longer drilled on the pins.
• The strength and service life of the pins are more than doubled, leading the industry.
• Using high-precision steel pipes, argon arc butt welding, and surface spraying to effectively extend the service life.
• New material dust-proof respirators are fully adopted to ensure system cleanliness and extend the service life of components.
• The new desert filter has better filtration effect, effectively protects the engine, and can calmly face high dust conditions.

Basic Technical Data:

• Operating weight: 22000kg
• Rated power: 129kw/2200rpm
• Standard capacity: 1.0 m³

Digging Stats:

• Max. Digging Radius: 9920mm
• Max. Digging Depth: 6680mm
• Max. Dumping Height: 9820mm

Additional Specifications
